DJI Mavic 3 Multispectral (M3M)

Product Description

DJI Mavic 3 Multispectral (M3M)

DESCRIPTION

The DJI Mavic 3M (Multispectral) sets a new standard for agricultural drones, offering advanced multispectral imaging capabilities to provide actionable insights for crop health management and mapping. Equipped with a 4/3 CMOS RGB camera and a multispectral sensor, the Mavic 3M allows users to visualize and analyze crop growth with unmatched clarity and precision.

With a max flight time of 43 minutes, a wind resistance of 12 m/s, and an RTK module for centimeter-level accuracy, this drone is designed for precision agricultural operations. Its lightweight, foldable design and omnidirectional obstacle sensing system ensure reliable performance in diverse environments. Whether you're surveying large fields or managing crop health, the DJI Mavic 3M is your go-to tool for smarter farming.

Key Features

• Dual Imaging System: Combines a 20 MP RGB camera and 5 MP multispectral camera for detailed analysis.
• Advanced Sensing: Includes omnidirectional obstacle sensing and RTK module for precise navigation.
• Extended Operation: 43 minutes of max flight time and 32 km max flight distance.
• Lightweight Design: Weighs only 951 g for easy transport and deployment.
• Agricultural Applications: Ideal for crop health analysis, precision mapping, and field surveying.

Detailed Specification

Aircraft

Attribute	Specification
Net Weight	951 g
Max Takeoff Weight	1,050 g
Dimensions (Folded)	223×96.3×122.2 mm
Dimensions (Unfolded)	347.5×283×139.6 mm
Max Flight Time	43 minutes
Max Wind Resistance	12 m/s
GNSS	GPS + Galileo + BeiDou + GLONASS

RGB Camera

Attribute	Specification
Sensor	4/3 CMOS, 20 MP
Lens	FOV: 84°, 24 mm equivalent, f/2.8–f/11
ISO Range	100-6400
Shutter Speed	Electronic: 8–1/8000 s, Mechanical: 8–1/2000 s
Max Image Size	5280×3956
Video Resolution	4K: 3840×2160@30fps

Multispectral Camera

Attribute	Specification
Sensor	1/2.8-inch CMOS, 5 MP
Bands	Green (560±16 nm), Red (650±16 nm), Red Edge (730±16 nm), NIR (860±26 nm)
Max Image Size	2592×1944
Photo Format	TIFF

Sensing System

Attribute	Specification
Type	Omnidirectional binocular vision and infrared
Obstacle Sensing Range	Forward: 0.5–20 m, Backward: 0.5–16 m
Effective Sensing Speed	≤15 m/s

RTK Module

Attribute	Specification
Positioning Accuracy	Horizontal: ±1 cm + 1 ppm, Vertical: ±1.5 cm + 1 ppm

Video Transmission

Attribute	Specification
System	DJI O3 Image Transmission Industry Edition
Max Transmission Distance	15 km (FCC), 8 km (CE/SRRC/MIC)

In Package

• 1x DJI Mavic 3M Aircraft with RTK Module & SD Card
• 1x DJI Enterprise Care Basic (1-Year Plan)
• 1x Remote Controller
• 3x Propeller Pair
• 1x Charger
• 1x Carrying Case
• 1x USB-C to USB-C Cable
• 1x Power Cable
• 1x USB-C Cable
• 1x Screwdriver
• User Manuals
